Cáp mạng Dintek treo ngoài trời - CAT.5e (thùng 305m)

• Cáp mạng outdoor Dintek CAT.5E UTP
• -       Cáp mạng CAT.5E UTP 4-pairs dùng ngoài trời, có dây gia cường để treo, móc, 305 mét/cuộn.
• -       Outdoor cat.5e 4 pair UTP solid twisted pair cable.
• -       Part number: 1101-03011A
• Cable Data
• -       Twisted pair color code:
• o   Pair 1> blue, white/blue ring.
• o   Pair 2> orange, white/orange ring
• o   Pair 3> green, white/green ring
• o   Pair 4> brown, white/brown ring
• -       Conductor: 24AWG (1x0.54 ± 0.007mm) solid Annealed copper wire
• -       Insulation material: HDPE
• -       Diameter of dielectric core: 1.03±0.05mm
• -       Insulation thickness: min AVG 0.245mm
• -       Number of twist pairs: 4 pairs
• -       Assembly: 4 pairs of dielectric core arranged in accordance with the structure figure.
• -       Waterblocking: Gel Filled Compound
• -       Material of jacket: PE
• -       Thickness of jacket: AVG 0.6 mm
• -       Nominal O.D.: Approx. 6.0 mm
• Electrical Characteristics
• -       Impedance: 100 Ohm  15%
• -       D.C.R (Max.) : 93.8 Ohm/100m at 20°C
• -       D.C.R. Unbalance (Max.) : 5% MAX./100m
• -       Temperature Rating : -40°C to 80°C
• -       Dielectric strength : DC 500V / 1min or AC 350V / 1min (Between wire and ground)
• -       Insulation Resistance: 1500 MOhm –Km  DC  500V (Between wire and ground)
•
• Applications
• -       Voice
• -       ISDN
• -       10Base T(IEEE 802.3)
• -       Fast Ethernet(IEEE802.3)
• -       100Vg-AnyLAN(IEEE 802.12)
• -       Token Ring(IEEE 802.5)
• -       TP-PMD(ANSI X3T9.5)
• -       100Base-T Ethernet(IEEE 802.3u)
• -       155/622 Mbps ATM
• -       1000Base-T
• -       550 MHz Broadband video
• Standards
• -       UL, ETL Verifi ed
• -       ANSI/TIA-568-C.2
• -       ISO/IEC 11801
• -       EN 50173
•  Sản xuất tại Taiwan.
